75 Inch Interactive Digital HD Board
An interactive digital board is a great way to get students engaged in learning. These boards have many features that allow for a variety of activities and materials to be used in instruction. For example, an interactive digital board can be used to show pictures, videos, and other media. Additionally, many of these boards have built in tools that allow for interactive activities, such as quizzes and games. The use of an interactive digital board can also help to promote student collaboration. This is because these boards can be used to share ideas and work on projects together.
Key Features
- screen sharing synchronized
- Integrated Android operating system and Windows
- Front mounted USB ports for Android and PC
- Physical function buttons
- Touch screen board
| Color |
|---|
Product Specification
| Display | Size: 65″ |
| TFT LCD Module with DLED Backlight | |
| 1431(H)*807(V)(64.5″ diagonal) | |
| Aspect Ratio: 16:9 | |
| Native Resolution: UHD 3840*2160 (Pixels) | |
| Color: 1.07B colors (10 bit) | |
| Brightness: 350 nits (typ.) | |
| Contrast Ratio: 6500:1 (DCR) | |
| Response Time: 5ms | |
| Viewing Angles: H=178, V=178 typ. | |
| Surface Treatment: Hardness: 7H, anti-glare coating | |
| Bezel: Slim | |
| Orientation: Landscape | |
| Android OS | Processor: ARM Cortex A73*2+Cortex A53*2 1.8Hz |
| RAM: 3GB DDR4 | |
| Storage: 32GB | |
| Touch | Type/Tech: IR Recognition |
| Touch Resolution: 32767*32767 | |
| Touch Point: 20 points touch, 10 points writing | |
| I/O Interface | HDMI: 2.0*3 (3840*2160 @60Hz) |
| RGB/VGA*1 | |
| Audio: *1 (PC audio in) | |
| RS232:*1 | |
| OPS: *1 PC Slot (proprietary) | |
| HDMI: 1*(4k/60Hz) | |
| Audio: *1 (Earphone out) | |
| SPDIF: 1 | |
| RJ45: *1 | |
| Type A: USB2.0: front*2(smart port for all), Rear*2 USB3.0: front*1 | |
| Type B: *2, for touch | |
| SPEAKERS: 12W*2 (Front position speakers)+15W*1 | |
| HDMI: 3840*2160 | |
| Embedded OS: Android 8.0 | |
| Others | Votage: 100-240V AC+/-10% Wide Range |
| Wall Mount (VESA): 500*400 | |
| Temperature: 0 to 40 | |
| Humidity: 10%-90% RH non-condesing | |
| Physical(mm):1483.2*884*91.8mm | |
| Packaging(mm):1600*1000*200mm | |
| Net(kg): 40kg | |
| Gross(kg): 48kg | |
| OPS (Can change) | Intel i3CPU, 4G RAM, 128G SSD |
| Intel i5CPU, 4G RAM, 128G SSD | |
| Intel i7CPU, 4G RAM, 128G SSD | |
| Certificate & Rack | We passed the following regulations: CE, ROHS, FCC |
| Floorstanding rolling trolley(OPTIONAL) | |
| Height Adjust: Yes | |
| We offer free WALL MOUNT BRACKET | |
| Physical(W*H*D): 1300*1600*650mm/51.2*63.0*25.6in | |
| Packaging(W*H*D): 1550*770*165mm/61*30.3*6.5in | |
| Net: 29.5kg/65.0lb | |
| Gross: 43.5kg/95.9lb | |
| OPS Spec available, can free to choose | |||||
| Android | Standard Windows | Medium Windows | High Windows | Top Windows | |
| Chip | Intel NM70 | ||||
| CPU | RK3368, Magny-Cours 1.8GHz | Dicaryon/ Quad-core | Intel Core i3 | Intel Core i5 | Intel Core i7 |
| Storage | 8GB EMMC (scalable) | Mainboard：OPS；hard disk：120G SSD（optional 4 and 8G or lager capacity hard disk） | Mainboard：OPS；hard disk：120G SSD （optional 4 and 8G or lager capacity hard disk） | Mainboard：OPS；harddisk：120G SSD（optional 4 and 8G or lager capacity hard disk） | Mainboard：OPS；harddisk：120G SSD （optional 4 and 8G or lager capacity hard disk） |
| Video card | Dicaryon/ Quad-core | Intel Core i3 | Intel HD Graphics | Intel HD Graphics | |
| Interface | USB*2；SD*1；Audio *1；LAN*1；WIFI*1 | 4 pieces USB2.0、2 piecesUSB3.0、one piece RJ45、1 piece MIC input、 1 piece HDMI output、1 piece VGA output、1 piece LINE output、WIFI 802.11b/g/n | |||
| OS | Android5.1 | Windows 7 , 8, 10 trial version | |||
