Grandstream GVC3220 Technical Specifications

Protocols/Standards

• SIP RFC3261, H.323,BFCP, TIP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE,LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP, TCP/IP/UDP, IPv6, OpenVPN®

MCU

• Up to 5-way video conferencing with 1080p @30fps, and 9-way with 720p @30fps conference

Camera

• 1/2.5“, 8 Megpixel CMOS, 4k 30fps or 1080p 60fps output

Lens

• 12x optical zoom,+/-30° tilt, +/-170° pan, 70.1°~7.4°(W) Field of View, 40.7°~4.2°(T) field of view

Network Interface

• 1× RJ4510/ 100/ 1000 Mbps

Wi-Fi

• Integrated dual-band Wi-Fi 802.11 a/b/g/n/ac (2.4GHz & 5GHz), supports Wi-Fi Multimedia

Bluetooth

• Integrated Bluetooth 5.0 + EDR

Video Outputs

• 1x HDMI 2.0 up to 4K, 1x HDMI 1.4 up to 1080p

Video Input

• 1x HDMI 1.4a with resolution up to 1080p

Microphone/Speaker

• Support external Bluetooth or 2.4G microphone, 1 built-in speaker.

Audio Input/Outputs

• 1x Line in/out ,1x Media

Remote Control

• Bluetooth and infrared remote control with multi-touch touchpad

Auxiliary Ports

• 1x USB 3.0 , 1x USB 2.0 , 1x SD, 1x Reset

Voice Codecs

• Support for G.711μ/a, G.722 (wide-band), iLBC, Opus , G.711, G.722.1, G.722.1c ,G729A/B, in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO)

Video Codecs

• H.264 BP/MP/HP, video resolution up to 4k, frame rate up to 30 fps, bit rate up to 8Mbps, H.265 BP/MP/HP, video resolution up to 4K, frame rate up to 30 fps, bit rate up to 8Mbps

Portrait Video Resolutions

• 4K from 1Mbps to 8Mbps, 1080p from 1Mbps to 4Mbps, and 720p from 512Kbps to 2Mbps

Content Video Resolution

• Input: 720p, 1080p (HDMI)
• Encoding: 800×600, 1024×768, 1280×1024, 1280×720, 1920×1080
• Output: 720p, 1080p

Dual-Stream

• BFCP, portrait video (up to 4K@30fps) + content video (up to 1080p@15fps)

Audio Features

• AEC, ANS, AGC, PLC, CNG/VAD

Video Features

• FEC, dynamic display layout, picture-in-picture, picture-outside-picture

Video Conferencing Service Platform

• SIP, H.323, Grandstream IPVideoTalk, Bluejeans and Zoom

Telephony Features

• Hold, mute, downloadable phone book (XML, LDAP), call waiting, call history, flexible dial plan, server redundancy & fail-over

Sample Applications

• Microsoft Teams, Skype or Skype for Business, Zoom, Youtube, API/SDK available for advanced custom application development

Application Deployment

• Allow various Android operation system 9.0 compliant applications to be developed, downloaded and run in the embedded device with provisioning control

QoS

• Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS

Security

• User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, 128/256-bit SRTP, HTTPS, 802.1x media access control

Multi-Language

• English, German, Italian, French, Spanish, Portuguese, Russian, Chinese and more

Upgrade/Provisioning

• Firmware upgrade via TFTP / HTTP / HTTPS or local HTTP upload, mass provisioning using TR-069 or AES encrypted XML configuration file.Detect U disk /SD card system version upgrade automatically

Power & Green Energy Efficiency

• Universal power adapter:
  – Input: 100~240Vac 50~60Hz
  – Output: 48V/1.35A(64.8W)

Package Content

• GVC3220 video conference system
• GMD1208 wireless microphone
• Remote control
• 4 AAA batteries
• Universal power supply
• Network cable (2 meters)
• HDMI cables (1x 5 meters, 2x 1.5 meters)
• Lens cleaning cloth
• Bracket
• Quick installation guide

Temperature and Humidity

• Operation: 0°C to 40°C
• Storage: -10°C to 60°C
• Humidity: 10% to 90% (Non-condensing)

Compliance

• FCC: Part15 Class B; Part 15 Subpart C 15.247; Part 15 Subpart E 15.407; MPE.
• CE: EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 62368-1; EN 301 489-1; EN 301 489-17; EN 300 328; EN 301 893; EN 62311.
• RCM: AS/NZS CISPR32; AS/NZS 4268; AS/NZS 62368.1.
• IC: ICES-003; RSS-GEN; RSS-247; RSS-102(MPE).
• HDMI/EAC/REACH/ROHS/WEEE
