Grandstream F-MM850-550M-1.25G SFP Fiber Module – Multimode 550m Transceiver

Grandstream

  • Supports data rates up to 1.25Gbps
  • Designed for multimode fiber (MMF) applications
  • Operating distance: Up to 550 meters
  • LC duplex connector for easy connectivity
  • 850nm wavelength transmission
  • Fully hot-swappable design
  • MSA-compliant SFP for wide compatibility
  • Ideal for enterprise, telecom, and data center networks

$17.76

Grandstream F-MM850-550M-1.25G Multi-Mode SFP Fiber Module

The Grandstream F-MM850-550M-1.25G is a high-performance multi-mode Small Form-Factor Pluggable (SFP) fiber module designed to deliver ultra-fast fiber connectivity for enterprise-class LAN and WAN environments. This hot-pluggable transceiver supports data rates up to 1.25 Gbps and operates over distances of up to 550 meters, utilizing an 850nm wavelength.

Engineered for reliability and efficiency, the module features a highly sensitive PIN receiver and integrated signal conditioning, making it ideal for Gigabit Ethernet applications requiring stable and secure data transmission.

Key Features

  • Multi-mode fiber support
  • 850nm wavelength
  • Transmission distance up to 550 meters
  • Data rate: 1.25 Gbps
  • Hot-pluggable SFP form factor
  • Low power consumption
  • Enhanced EMI shielding and ESD protection

This module is particularly well-suited for enterprise networks and optical link deployments where energy efficiency and consistent performance are critical.


Important Notes

  • Always match the fiber cable type to the module: use multi-mode fiber with multi-mode modules and single-mode fiber with single-mode modules.
  • Ensure the wavelength of the fiber cable aligns with the module’s specifications.
  • Select the appropriate SFP module based on your network’s transmission distance and topology requirements.
  • This is a Class 1 Laser Product. Do not look directly into fiber connectors or ports, as exposure to laser radiation may be harmful to the eyes.



Brands

Color

Fiber Mode

Single-Mode Fiber

Operation Voltage

3.3V±0.3V

Grandstream F-MM850-550M-1.25G Technical Specifications

brandGrandstream
 Fiber ModeMulti-Mode Fiber
Connector TypeDuplex LC
DDMYes, I2C for integrated Digital Diagnostic Monitoring
Nominal Wavelength850nm
Data Rate1.25Gbps SFP
Max Power Consumption0.8W
Transfer Distance50/125μm(OM2): 0.55km

62.5/125μm(OM1): 0.3km

TX Power-10 to -3dBm, ±3dB
RX Power-18 to -3dBm, ±3dB
Operation Voltage3.3V±0.3V
EnvironmentalOperation: 0℃ to 70℃, humidity: 5% to 85%

Storage: -40℃ to 85℃

Unit Weight15.80g
StandardsSFF-8472, SFP MSA, IEEE 802.3z, RoHS-6
ComplianceFCC, CE, FDA
