Grandstream GWN7605 Dual-Band WiFi Access Point | 2x Gigabit Wireline Ports | Advanced QoS to ensure Real-time Performance


  • 2xGigabit wireline ports
  • Dual-band 2×2:2 MU-MIMO
  • Beamforming technology
  •  Self power adaptation upon auto detection of PoE/PoE+
  •  1.27Gbps aggregate wireless throughput
  • Supports 100+ concurrent Wi-Fi client devices
  • Up to 165-meter coverage range
  • Advanced QoS to ensure real-time performance
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures
  • Unique security certificate/random default password per device
  •  Embedded controller can manage up to 50 local GWN series APs
  • GWN.Cloud offers unlimited AP management and premise-based software controller

$70.50

Compare
$114.37 for 3 item(s)

Grandstream GWN7605 Dual-Band WiFi Access Point | 2x Gigabit Wireline Ports | Advanced QoS to ensure Real-time Performance

Affordable Grandstream GWN7605 Dual-Band Wi-Fi access point is the ideal WiFi access point for small to medium wireless network with medium user density. It offers dual-band 2×2:2 MU-MIMO with beam-forming technology and a sophisticated antenna design for maximum network coverage range. Dual-Band Wi-Fi Access ensures easy installation and management, the GWN7605 uses a controller-less distributed network management design in which the controller is embedded within the product’s web user interface.

It is the ideal Wi-Fi AP for voiceover-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi-capable IP phones. This WiFi access point also supports advanced QoS, low-latency real-time applications, mesh networks, captive portals, 100+ concurrent clients per AP and dual Gigabit network ports with PoE/PoE+. This GWN7605 Dual-Band Wi-Fi Access is truly a scalable Wi-Fi solution for deployments such as retail locations, restaurants, small offices and more.

Features of Grandstream GWN7605 Dual-Band WiFi Access Point:

  • 2xGigabit wireline ports
  • Dual-band 2×2:2 MU-MIMO
  • Beamforming technology
  •  Self power adaptation upon auto detection of PoE/PoE+
  •  1.27Gbps aggregate wireless throughput
  • Supports 100+ concurrent Wi-Fi client devices
  • Up to 165-meter coverage range
  • Advanced QoS to ensure real-time performance
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures
  • Unique security certificate/random default password per device
  •  Embedded controller can manage up to 50 local GWN series APs
  • GWN.Cloud offers unlimited AP management and premise-based software controller
BrandGrandstream

WiFi Standards

  • IEEE 802.11a/b/g/n/ac (Wave-2)

Antennas

  • 2 dual band internal antennas
  • 2.4GHz, gain 3dBi
  • 5 GHz, gain 3dBi

WiFi Data Rates

  • IEEE 802.11ac: 6.5 Mbps to 867 Mbps
  • IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
  • IEEE 802.11n: 6.5Mbps to 300Mbps;
  • IEEE 802.11b: 1, 2, 5.5, 11 Mbps
  • IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
  • *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network

Frequency Bands

  • 2.4 GHz Radio: 2412 – 2484 MHz
  • 5 GHz Radio: 5180-5825 MHz

Channel Bandwidth

  • 2.4G: 20 and 40 MHz
  • 5G: 20,40 and 80 MHz

WiFi And System Security

  • WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES), anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device

MIMO

  • 2×2:2 2.4GHz (MIMO)
  • 2×2:2 5GHz (MU-MIMO)

Coverage Range

  • Up to 165 meters
  • *coverage range can vary based on the environment

Maximum TX Power

  • 2.4G:24dBm
  • 5G:22dBm
  • *Maximum power varies by country, frequency band and MCS rate

Receiver Sensitivity

  • 2.4G: 802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
  • 5G: 802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40:- 63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9

SSIDs

  • 8 SSIDs per radio

Concurrent Clients

  • 100+

Network Interfaces

  • 2 x autosensing 10/100/1000 Base-T Ethernet Ports

Auxiliary Ports

  • 1 x Reset Pinhole, 1 x Kensington lock

Mounting

  • Indoor wall or ceiling mount, kits included

LEDs

  • 3 x tri-color LED for device tracking and status indication

Network Protocols

  • IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM

QoS

  • 802.11e/WMM, VLAN, TOS

Network Management

  • Embedded controller can manage up to 50 local GWN APs
  • GWN.Cloud offers a free cloud management platform for unlimited GWN APs
  • GWN Manager offers premise-based software controller for up to 3,000 GWN APs

Power And Green Energy Efficiency

  • PoE 802.3af/ 802.3at;
  • Maximum Power Consumption:10.16W

Environmental

  • Operation: 0°C to 40°C
  • Storage: -10°C to 60°C
  • Humidity: 10% to 90% Non-condensing

Physical

  • Unit Dimension: 180.4mmx180.4mmx40.8mm;
  • Unit Weight: 388.2g
  • Entire Package Dimension: 228.5x220x79mm;
  • Entire Package Weight: 719.3g

Package Content

  • GWN7605 802.11ac Wireless AP, Mounting Kits, Quick Start Guide

Compliance

  • FCC, CE, RCM, IC
