Receiver Rolling fixed Code DC 12V - 24V
[digitnet_promo_icons]
Product Description
This receiver is a multi-purpose intelligent controller that can be used with most
wireless remote controllers on the market, including fixed codes (2262, 2260, 2264, 5326,M1E, M5E, etc.)
Main Features
- Frequency: 315MHZ,433mhz
- Receiving Sensitivity -100db
- Β Output current β€8A
Β
- Brands: Champions
- Color: White
4 in stock
Click any tab above to view the information.
Description
Receiver Rolling fixed Code DC 12V – 24V
433Mhz DC 12V – 24V Rolling fixed Code Receiver garage gate Remote control switch Working Mode Matching method:
Accessories
This section can show compatible accessories, installation kits, cables, brackets, batteries, or related add-ons.
Compatible accessories will appear here when assigned in Product Data > Accessories.
Specifications
This section shows product attributes such as brand, model, SKU, power, size, material, color, and compatibility.
Working Voltage | 12V~36 VοΌDC/ACοΌ |
Output Current | β€8A |
Working Frequency: | 315MHZ,433mhz |
Receiving Sensitivity | -100db |
Function option | Momentary/Toggle |
Modulation Mode | ASK |
Matching Mode | Intelligent Learning code |
Output Mode | Dry contact (switch signal) |
Working temperature | -40β- +80β |
Dimension | 95*60*30mm |
Transmitting Distance: | 60-100 Meter(open space) |
Certification: | CE, ROHS |
Technical Specifications
| Brands | Champions |
|---|---|
| Color | White |
