The Dinstar UC2000-VE-4G 4 Port GSM VoIP Gateway

Availability:

Out of stock


Key Features

      • 16 GSM/CDMA/WCDMA Channels
      • Support to different mobile networks
      • GSM: 850/900/1800/1900MHz

Downloads Documents & Manuals
 Dinstar UC2000 VE Datasheet (PDF)

Temporarily out of stock

$1,739.00 $1,739.79

Out of stock

Dinstar UC2000-VE-4G 4 Port GSM VoIP Gateway  is the most cost-effective, easy to use VoIP GSM gateway on the market. It supports both Analog and GSM networks, which provides a seamless experience for your business. The Dinstar UC2000-VE-4G 4 Port also comes with 4 ports to give you the perfect amount of flexibility and scalability when it comes to expanding your business.

The Dinstar UC2000-VE-4G 4 Port GSM  multi-functional gateway helps to effectively implement calls between 2G/3G mobile networks and VoIP networks. Furthermore, with its newly designed pop-up SIM card slot, users can change the SIM card easily without dismantling the device. Moreover, with the opened API feature of this gateway, you can build your application software that will allow for sending SMS messages or USSD messages. This product has excellent features and hardware design performance at a low cost! If you’re looking for an efficient but affordable solution, consider this product today.

Dinstar UC2000-VE-4G 4 Port  is an ideal gateway for small or large offices as it provides the flexibility of usage with its wide range of features and benefits:

Dinstar UC2000-VE-4G Key Features

    • 4 or 8 GSM/CDMA/WCDMA Channels supported on UC2000-VE
    • Support to different mobile networks:
    • GSM: 850/900/1800/1900MHz;
    • CDMA: 800MHz; WCDMA: 850/900/1900/2100MHz
    • HTTP API for SMS Application Integration
    • SMS to Email and Email to SMS
    • Flexible Dial Rules and Manipulation Rules



Category:

Dinstar UC2000-VE-4G – Technical Specifications
Voice Processing
Protocol: SIP v2.0, RFC3261
Codecs:G.711A/U law, G.723.1, G.729A/B
Silence Suppression
Comfort Noise Generator(CNG)
Voice Activity Detection(VAD)
Echo Cancellation: G.168 with up to 128ms
Dynamic Jitter Buffer
DTMF: RFC2833, SIP Info
Call Progress Tone Generation
Programmable Gain Control
NAT: STUN, Dynamic NAT, Static NAT
Mobile
SIM Interface: 1.8v, 3.0v SIM Interface
Frequency Range:
GSM: 850/900/1800/1900MHz;
CDMA: 800MHz
WCDMA:850/900/1900/2100MHz
USSD Encoding: Unicode/ASCII
HTTP API for SMS
Polarity Reversal
PIN Modify
CID/CLIR
SMS Send and Receive
SMS to Email
Call Waiting/Call Back
Call Forward
GSM Audio Coding: HR, FR,EFR, AMR_FR,AMR_HR
Software Features
Calling Type:
Mobile to VoIP, VoIP to Mobile
SIP Trunk and Trunk Group
Caller/Called Number Manipulation Rules
SIP Codes Mapping
White/Black List
PSTN Hotline
VoIP Hotline
Abnormal Call Monitor
Call Minutes Limitation for Ports/Single Call
Balance Check
Low Balance Alarm
Auto Update SIM Number
Random Call Interval
Auto CLIP
Signaling & RTP Encryption
SMPP for SMS
Network
Static IP, DHCP Client, PPPoE
Network Protocols:
TCP/UDP,TFTP, FTP, RTP/ RTCP, SSH,ARP,RARP,ICMP Ping, NTP, HTTP, DNS
Static/Dynamic ARP Request
PPTP VPN
Maintenance
Web/Telnet Configuration
Configure Backup/Restore
Firmware Upgrade by HTTP/TFTP
Factory Reset
CDR (10000 Lines CDRs Storage Locally)
Syslog/Filelog
Ping and Tracert
Traffic statistics: TCP,UDP,RTP
VoIP Call Statistics
PSTN Call statistics: ASR,ACD,PDD
Voice Diagnose with Loopback
GSM Network Test
IVR Customization
Auto Provisioning
SIP/RTP/PCM Capture
Physical Interface
Mobile: 4/8 Channels
Antennas Connectors: SMA
Ethernet Interfaces:2*10/100 Base-T, RJ45
LED Indicators: Power, RUN, Signal Strength Indicators
Console:1* RS232 115200bps
Environmental
Power Supply
Input:100-240V,50-60Hz
Output: DC12V 4.0A
Power Consumption:
UC2000-VE-4G: 20w
UC2000-VE-8G: 25w
Temperature(Operation): 0 ℃ ~ 45 ℃(Storage): -20 ℃ ~80 ℃
Operation Humidity: 10%-90% No Condensation
Dimension(W/D/H): 250*156*32.5mm
Weight: 1.069kg
Package Weight: 2.05kg
