Receiver Rolling fixed Code DC 12V - 24V
Access Control, 280Kg Magnetic Lock, Electromagnetic Door Lock, Electromagnetic Lock
Receiver Rolling fixed Code DC 12V – 24V
$4,600
Availability:
4 in stock
Product Description
This receiver is a multi-purpose intelligent controller that can be used with most
wireless remote controllers on the market, including fixed codes (2262, 2260, 2264, 5326,M1E, M5E, etc.)
Main Features
- Frequency: 315MHZ,433mhz
- Receiving Sensitivity -100db
- Output current ≤8A
$4,600
4 in stock
Receiver Rolling fixed Code DC 12V – 24V
433Mhz DC 12V – 24V Rolling fixed Code Receiver garage gate Remote control switch Working Mode Matching method:
1.Matching method of Momentary mode:
Press the code matching button on the control panel, the LED indicator will flashes. Then press the remote control button that needs to be paired, and the controller board LED indicator flashes 5 times means in success.
2.Matching method of Toggle mode:
Press the control panel pairing button twice, the LED indicator flashes 2 times, press the remote control button that needs to be paired, and the controller board LED indicator flashes 5 times continuously means in success.
| Brands | |
|---|---|
| Color |
Specification:
Working Voltage | 12V~36 V（DC/AC） |
Output Current | ≤8A |
Working Frequency: | 315MHZ,433mhz |
Receiving Sensitivity | -100db |
Function option | Momentary/Toggle |
Modulation Mode | ASK |
Matching Mode | Intelligent Learning code |
Output Mode | Dry contact (switch signal) |
Working temperature | -40℃- +80℃ |
Dimension | 95*60*30mm |
Transmitting Distance: | 60-100 Meter(open space) |
Certification: | CE, ROHS |
