ONV-H3108P Full Gigabit 10-Port Poe Switch
Network Switch, network switch 10 port, network switch 8 gigabit, onv 8gb switch, ONV Network SwitchONV-H3108P Full Gigabit 10-Port Poe Switch
Got A Question? Contact Us.
We Offer Good Discount Expert Technical Support
Key feature
- 8*10/100M Poe ports,802.3af/at+2*10/100/1000M RJ45 ports
- Max power per Poe port:30W.
- Port 1-8 support 10M@long transmission distance 120 meters
- Supply power with the spare line pair
- Port 1-8 support 10M@long transmission distance 250 meters and VLAN optional
- Built-in power supply
ONV-H3108PL Datasheet (PDF)
ONV Warranty Terms (PDF)
ONV-H3108PS Application (JPEG)SKU: H3108PS - Network Switch, network switch 18 port, network switch poe, ONV Network Switch, onv switch 16 port, power strip with usb port
ONV-H1016PL 18 Port Unmanaged Poe Switch for Small & Medium Businesses
Network Switch, network switch 18 port, network switch poe, ONV Network Switch, onv switch 16 port, power strip with usb portONV-H1016PL 18 Port Unmanaged Poe Switch for Small & Medium Businesses
Got A Question? Contact Us.
We Offer Good Discount Expert Technical Support
Key feature
- 16*10/100M Poe ports,802.3af/at+2*10/100/1000M RJ45 ports
- Max power per Poe port:30W.
- Port 9-16 support 10M@long transmission distance 250 meters
- Supply power with the spare line pair
- Built-in power supply
ONV-H1024PL Datasheet (PDF)
ONV Warranty Terms (PDF)
H1024PL Application (JPEG)SKU: NS1000 - Network Switch, network switch 24 gigabit, onv 24gb switch
ONV-H1024PL Gigabit Uplink PoE Switch for High Speed, Rack Mountable
Network Switch, network switch 24 gigabit, onv 24gb switchONV-H1024PL Gigabit Uplink PoE Switch for High Speed, Rack Mountable
Got A Question? Contact Us. Exclusive Offers
Great Deals And Huge Savings Expert Technical Support
Key feature
- 16*10/100M Poe ports,802.3af/at+2*10/100/1000M RJ45 ports
- Max power per Poe port:30W.
- Port 9-16 support 10M@long transmission distance 250 meters
- Supply power with the spare line pair
- Built-in power supply
SKU: H1024PL
ONV-H3108P Full Gigabit 10-Port Poe Switch
2 in stock
Got A Question? Contact Us.
We Offer Good Discount Expert Technical Support
Key feature
- 8*10/100M Poe ports,802.3af/at+2*10/100/1000M RJ45 ports
- Max power per Poe port:30W.
- Port 1-8 support 10M@long transmission distance 120 meters
- Supply power with the spare line pair
- Port 1-8 support 10M@long transmission distance 250 meters and VLAN optional
- Built-in power supply
ONV-H3108PL Datasheet (PDF)
ONV Warranty Terms (PDF)
ONV-H3108PS Application (JPEG)
$32.00
2 in stock
ONV-H3108P Full Gigabit 10-Port Poe Switch
The ONV-H3108P 10-Port Poe Switch is a powerful, feature-rich device that is perfect for any business or home office network. Newly released ONV-H3108P from Optic Network Video is a full gigabit 10-port POE switch that offers an affordable, high-performance solution for businesses of all sizes. This switch provides eight 10/100/1000BASE-T POE ports with a maximum of 30W per port, and two SFP slots for uplink connectivity. It is designed for use in homes and small businesses. The switch is easy to install and use, and it offers a variety of features that make it a great choice for those looking for a fast and reliable switch.
The ONV-H3108P is a 10-port PoE switch is ideal for businesses looking to deploy IP cameras, VoIP phones, and other PoE-powered devices.
FEATURE
10/100M access, Gigabit uplink
- Has 8*10/100M PoE ports and 2*10/100/1000M RJ45 ports for easy connection
- It is suitable for various networking requirements
- Support non-blocking wire-speed forwarding.
- Compatible with full-duplex based on IEEE802.3x and half-duplex based on backpressure.
Stable and reliable, easy to use
- CCC,CE, FCC, RoHS.
- Supports 1U-19 inch cabinet rack.
- No setup required, simple plug and play.
- Galvanized steel case, low power consumption, no fan.
- Displays devices status through the LED indicator of power.
ECHNICAL SPECIFICATION
Model | ONV-H3064PS | ONV-H3108PS |
Interface Characteristics | ||
Fixed Port | 4*10/100/1000Base-T PoE ports (Data/Power) 2*10/100/1000Base-T uplink RJ45 ports (Data) | 8*10/100/1000Base-T PoE ports (Data/Power) 2*10/100/1000Base-T uplink RJ45 ports (Data) |
Ethernet Port | Port 1-6/ Port 1-10 support 10/100/1000Base-T auto-sensing, full/half duplex MDI/MDI-X self-adaption | |
Twisted Pair Transmission | 10BASE-T:Cat3,4,5 UTP(≤100 meter) 100BASE-TX:Cat5 or later UTP(≤100 meter) 1000BASE-T : Cat5e or later UTP(≤100 meter) | |
Chip Parameter | ||
Network Protocol | IEEE802.3 10BASE-T, IEEE802.3i 10Base-T IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3x | |
Forwarding Mode | Store and Forward(Full Wire Speed) | |
Switching Capacity | 16Gbps (Non-blocking) | 20Gbps (Non-blocking) |
Forwarding Rate@64byte | 8.93Mpps | 14.88Mpps |
MAC | 8K | 2K |
Buffer Memory | 2M | |
Jumbo Frame | 9.2k | |
LED Indicator | Power: PWR (Green), Network: Link (Green), PoE: PoE (Green) | |
PoE & Power Supply | ||
PoE Port | Port 1 to 4 | Port 1 to 8 |
Power Supply Pin | Default 1/2(+), 3/6(-) | |
Max Power Per Port | 30W, IEEE802.3af/at | |
Total PWR / Input Voltage | 65W/ (AC100-240V) | 120W/ (AC100-240V) |
Power Consumption | Standby <5W, Full load <65W | Standby <6W, Full load <120W |
Power Supply | Built-in power supply, AC100~240V 50-60Hz 1.1A | Built-in power supply, AC100~240V 50-60Hz 2.2A |
Physical Parameter | ||
Operation TEMP / Humidity | -20~+55°C,5%~90% RH Non condensing | |
Storage TEMP / Humidity | -40~+75°C, 5%~95% RH Non condensing | |
Dimension (L*W*H) | 195*130*40mm | 195*130*40mm |
Net /Gross Weight | <0.6kg / <1kg | <0.9kg / <1.2kg |
Installation | Desktop, wall-mounted | |
Certification & Warranty | ||
Lightning Protection | Lightning protection: 4KV 8/20us, Protection level: IP30 | |
Certification | CCC, CE mark, commercial, CE/LVD EN60950, FCC Part 15 Class B, RoHS | |
Warranty | 1 year, lifelong maintenance. |
