Grandstream GWN7700P Unmanaged POE Switch
Grandstream GWN7700P Unmanaged POE Switch
, , , ,

Grandstream GWN7700P 5-Port Gigabit 4-Port PoE+ Switch

Grandstream
Compare

Got A Question? Contact Us.      Exclusive Offers

Great Deals And Huge Savings    Expert Technical Support

  • 4 POE ports
  • 5 Gigabit RJ45 ports, 4 port PoE+ output
  • Green technology reduces power consumption
  • LED Indicators; Per port: Link/Activity/Speed Per device: Power
  • Auto MDI/MDIX crossover for all ports

Grandstream GWN7811(P) – GWN7812(P) – GWN7813(P) Datasheet





$39.00

Compare
$228.50 for 3 item(s)

Introducing the GWN7700 Series: Effortless Gigabit Connectivity

Experience seamless Gigabit connectivity with the GWN7700 series, tailored for home offices and small/medium businesses. These unmanaged network switches offer a hassle-free setup, requiring no configuration or installation. Designed with versatility in mind, they feature a desktop and wall-mountable design, ensuring flexibility in placement.

Enjoy hassle-free compatibility with each port supporting auto-negotiation, automatically recognizing the link speed of any 10/100/1000Mbps network device. Say goodbye to crossover cables with auto MDI/MDIX functionality.

For added convenience, PoE (Power-over-Ethernet) models feature IEEE 802.3af/at compliant ports, delivering smart dynamic PoE output to power various devices like IP phones, cameras, and Wi-Fi access points.

With plug-and-play simplicity, the GWN7700 series is the go-to choice for enhancing network connectivity in home offices and small-to-medium businesses.

Grandstream GWN7700P  Feautures

  • 5 Gigabit RJ45 ports, 4 port PoE+ output
  • Green technology reduces power consumption
  • LED Indicators; Per port: Link/Activity/Speed Per device: Power
  • Auto MDI/MDIX crossover for all ports
  • 802.3 af/at compliant Up to 30W on each port,
  • Broadcast/Multicast/Unicast Storm Control (fixed to 100Mbps) to monitor traffic levels
  • QoS – Supports Default Strict Priority when present

For Technical Support Contact

Related Products

SKU: GWN7700P Categories: , , , , Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , , ,
Weight0.27 kg
Dimensions230 × 190 × 51 mm
Brands

Color

Number of Ports

4-Ports

Grandstream GWN7700P Technical Specifications

BrandGrandstream
Gigabit Ports5
PoE Ports4
Metal
MountingDesktop/ Wall-Mount
Standards and

Protocols

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Port Feature5× 10/100/1000Mbps RJ45 Ports

AUTO Negotiation

AUTO MDI/MDIX

Network Media1000Base-T/100Base-TX/10Base-T, Half/Full-Duplex
PoE Configuration

1~4 Ports 802.3 af/at compliant

Up to 30 W on Each Port, Total 60W Power Budget;

Overload to cut off the lowest-priority port.

Priority: Port 4 to Port 1



LED IndicatorsPer port: Link/Activity Green

Per device: Power Green

Mac Address Table2K
Switching Capacity10Gbps
Jumbo Frame9KB
Advanced FeaturesMac Address Auto-Learning And Auto-Aging

IEEE 802.3x Flow Control

802.1p/DSCP QoS

IGMP:

IGMP Fast-Leave

IGMP Snoop

Route Port Autolearn

Query Refresh Member Port



Power AdapterExternal 48-53.5VDC/1.22A
Max Power Consumption by Base System2W (excluding PoE output power)
EnvironmentalOperating Temperature: 0 to 40 °C (32 to 104 °F)

Storage Temperature: -40 to 60 °C (-4 to 140 °F)

Operating Humidity: 10% to 90% Non-condensing

Storage Humidity: 5% to 90% Non-condensing

Dimensions (L x W x H)Unit: 145 x 80 x 27mm

Package: 230 x 190 x 51mm

WeightUnit Weight: 0.26KG

Entire Package: 0.75KG

Package1x Switch, 1x Power Adapter,1x QIG
ComplianceFCC, CE, RCM, IC, UKCA
